Space-heating accounts for 35% of total energy-related emissions in Ireland today. As one key component of its response to the National Climate Action Plan, South Dublin County Council (SDCC) committed to the decarbonisation of its county-town, Tallaght. Nationally, decarbonisation will rely on increasing renewable generation assets – wind and solar – on the grid to a target of 85% by 2030. This will enable significant carbon-savings through the widespread electrification of the heat and transport sectors.

‍

The Tallaght District-Heating (DH) Scheme was identified as a pilot project to promote this switch to low-carbon, renewable heating. 70% of the Dublin region is suitable for adaptation to DH (increasing to 86% in the city centre). There are sufficient waste heat sources in Dublin to service the equivalent of 1.6 million homes; DH can recycle and harness this waste heat as a low-carbon resource for space-heating.

‍

In 2016, as part of a five-city EU Inter-Reg programme to foster DH technology in northern Europe, €950,000 was made available (including €347,000 from SDCC resources) to underwrite initial work on the Tallaght DH network. This seed-funding allowed the formation of South Dublin District-Heating Company – Ireland’s first not-for-profit, publicly-owned heat utility, now trading as ‘Heat Works’.

‍

The DH network was envisioned, championed, and project managed by the SDCC Architects Department, building on experience installing CHP, solar arrays, heat pumps, and bio-mass boilers in public buildings over a twenty-year period. The DH scheme was a collaboration between SDCC, Amazon, Fortum (the contractor), and the Dublin energy agency Codema, which has provided a low-carbon solution, optimising the potential of recyclable heat combined with innovative heat-pump technology. Heat Works is set up to act as an exemplar heat-network business in Ireland, delivering economic, environmental, and social benefits for residents and businesses while supporting the local and national climate action plans by reducing our carbon footprint.

‍

Heat Source

At this time, Amazon Web Services (AWS) were planning a large data centre in Tallaght. As part of pre-planning discussions with SDCC, AWS agreed to collect and make available waste-heat from the data-centre’s cooling-system to the DH network. As part of this agreement, waste-heat collection equipment and ongoing heat delivery to Heat Works will be at the expense of AWS in line with their company commitment to global carbon-reduction. The Tallaght DH network is the first scheme in Ireland to capture and efficiently re-use waste heat from a large-scale data centre using bespoke 4G district-heating technology. 10MW of waste-heat is available for use in the Tallaght network on this basis.

‍

‍

It is currently estimated that by 2028 data centres may be using up to 29% of the national grid, and by 2030 will have added 13% to carbon-emissions on the grid. While not eliminating all primary energy use, DH can seriously offset the generation of both heat and carbon for space-heating required by DH customers and greatly reduce carbon emissions discharging energy-intensive waste-heat from cooling systems in data centres.

‍

The Energy Centre and Pipe-Network

To utilise the waste-heat generated by AWS, a distinctive zinc-clad Energy Centre was constructed adjoining the data centre to collect, consolidate, and distribute hot-water to the DH network. The hot air from AWS is collected and run through a heat-pump to raise the temperature of water to 25-27°C. This water is then transferred to the Heat Works Energy Centre building where the temperature is raised again through bespoke centralised large-scale heat pumps to 85°C and sent through the pipe network. In turn, the servers in the data centre are provided with cool air as a by-product from the Energy Centre. The Energy Centre also includes full peak load back-up via a 3MW electric boiler to ensure heat supply to the network can be met at all times. The scheme is fully electric with no on-site combustion resulting in the elimination of particle emissions. In addition, the carbon content of the heat will continue to reduce over time in line with the decarbonisation of the national grid through increased deployment of renewable sources, e.g. onshore / offshore windfarms, solar power, etc [1].

‍

This Tallaght DH scheme is currently providing both space-heating to buildings on the DH network and cooling to the data centre [2]. The scheme currently has planning permission for 400m³ of thermal water-storage. In time, this will enable greater flexibility and utilisation of off-peak electricity, which will increasingly enable the DH network to support the grid by providing greater demand-side response services to regulate large fluctuations associated with wind-power generation. The initial pipe network measures 1.6km in length, utilising different sizes of pre-insulated pipes to ensure minimal thermal losses. Hot water is distributed to customer buildings through the pipe network from the Energy Centre. Heat exchanger substations are located within the customer buildings with an indirect system (the network water crosses and heats the customers’ water, but they do not mix). Energy meters measure the amount of thermal energy used by the customer for heating spaces, HVAC systems, and sanitary hot water.

‍

‍

Overall, the Tallaght DH Scheme produces CO₂ savings of 1500 tonnes per annum in the first phase of the scheme along with a reduction of 528kg in nitrogen oxide emissions. This will increase as the scheme expands and the input of renewably-generated electricity increases. In effect, fossil-fuel usage will be reduced by 100% as the grid is made fully renewable. The lack of combustion onsite eliminates particulates and provides cleaner air for Tallaght town centre.

‍

In addition to road testing DH generation and control technologies in Ireland, the Tallaght scheme was set up to trial the legal, financial, procurement, and governance structures required for a heating network in Ireland. A series of innovative contract types had to be developed for the project carried out under the skilful direction and experience of Philip Lee and Associates Solicitors. The fledgling company required an experienced energy-supply company (ESCO) to design, construct, and operate the DH network. This role was tendered across the whole of the EU using the OJEU process. The tender was arranged as a ‘Competitive Dialogue’ in three stages culminating in the submission of a final design and financial bid. This included the design of the Energy Centre and the distribution pipe network. The preferred bidder was Fortum, a multi-national ESCO based in Finland with extensive experience in DH across the Nordic countries and Eastern Europe.

‍

Procurement Models

A Local Energy-Supply Contract (Design, Build, Operate, & Maintain – DBOM) between the ESCO and Heat Works was agreed. This contract is divided in two phases – Construction Phase (Design & Build), and Operation Phase (Operate & Maintain). Heat Works buys the heat produced from the ESCO based on a fixed operational carbon-efficiency figure. The manner in which this heat is produced, and the risks associated with its production is the responsibility and risk of the ESCO, and the cost of electrical supply is at the risk of Heat Works. A separate new contract had to be developed and agreed to address the transfer of waste heat from AWS to Heat Works, and the return of lower-temperature water from the DH network to AWS to assist in cooling within the data centre.

‍

‍

A customer-contract was also required addressing the sale of heat from Heat Works to each customer. Heat Works are responsible for customer relations and calculation of customer bills. Monthly customer bills include fixed components (two standing charges for administration and network maintenance), and a variable charge for quantity of heat supplied. The initial customers are SDCC (County Hall and Library, the Innovation Centre, and two-hundred affordable apartments) and TUD Tallaght (main campus building, SSRH sports building, and the North Block Catering College). To date, 70,000m² of space are connected to the Tallaght network, and total investment stands at €8 million [3].

‍

The contract for Design, Build, Operate, and Maintenance was signed in October 2020 and works commenced in 2021. Works were directly affected by COVID-19 government-imposed site closures. Testing began on the plant and network during October, November, and December 2022. Heat was delivered to first customers from 19 January 2023 with Substantial Completion achieved in July 2023. Since then, the district-heating scheme has been in its Operation and Maintenance phase.

Graduates of architecture in the Republic of Ireland are facing a new significant barrier to accreditation, much discussed among affected individuals for the past year. What is a long journey to becoming an architect has, since the beginning of 2023, become implausibly longer again for many students as one of the two universities that offer the Professional Diploma in Architectural Practice in Ireland (PDAP – legally labelled the Professional Practice Exam, or PPE) decided to cease its offering to new applicants for at least three years – up to 2026 at the earliest [1]. This reduced the number of places available from a previous average of roughly 140 per year to the seventy places remaining at the only other university in Ireland which offers the course. In September 2024, this number will reduce again, as the remaining university removes twenty-two places from its offering. With five Irish universities producing roughly 200-250 graduates per year, combined with the number of expatriates working in Ireland in the architectural profession and requiring professional exams – this has resulted in a situation where there are, at the time of writing, around 400 expressions of interest vying for forty-eight places for the single PDAP course. This means that only one in eight to ten applicants will get a place, with the possibility for further growth to these numbers year-on-year.

‍

‍

In April 2024, while the RIAI issued an updated statement on the dwindling capacity problems, with the welcome proposal of facilitating the PPE themselves from 2025, they did not specify how many graduates this course would accommodate, nor give any indication how much it would cost [2]. The problem is inevitably clogging the system with graduates, who have project and salary expectations that are determined by the timeline within which they complete the PPE. The current delays consequently are affecting their plans of a rational timeframe for career progression. Employers, too, will be directly affected, as they become encumbered with graduates who cannot progress through the system reasonably, and who they thus cannot expect to charge for as registered architects, or whose CVs they may not use to their full potential to win work. What should be even more alarming for the renowned richness of the profession in Ireland is how the backlog is delaying the beginning of the careers of potential sole-practitioners, previously a significant proportion of practising architects. In facing the current delays in starting the PPE, all graduates objectively must contend with a lag before they are provided the opportunity to contribute their ideas, ability, and energy to the industry in Ireland. Professional roadblocks could, and are, becoming repercussive personal reckonings for many, that arguably conclude with emigration to countries with more responsive registration systems as the only viable solution.

‍

While legal protection for the title 'Architect' has been a persistent part of the RIAI’s two-fold aim of protecting and promoting members since 1885 [3], the role of the architect and the associated PPE was only legislatively defined by Part 3 of the Building Control Act 2007, which also bestowed upon the RIAI with the legal responsibility to manage accreditation of that title [4]. Part 3 of the Act was not “intended to exclude anybody, but, rather, to include all those who meet a defined minimum standard” [5]. In the current climate, the backlog in achieving accreditation has become so restrictive that graduates of the industry are potentially being prevented, legally, from working independently in it. This hard-won and necessary tool to protect the profession is now rendered as the means by which its reputation is tarnished – through exclusion of new members.

‍

‍

The situation reveals a functional issue within the increasingly fragmented structure of the pathway to becoming an architect. The industry’s typically younger members, who have studied as long and as hard as those before them, have danced through the same rules but have reached a surprise stumbling block right at the very end. These members are becoming extremely frustrated with the slow pace of any resolution to a worsening problem. The immediate function and future of an industry cannot and should not subside because of the decision to close one course, and improved access to the profession should be increased in line with demand for university places and PPE courses to secure its future. The welcome development of a new course by the RIAI should be the beginning. Members of the industry at all levels should also galvanise government support for the formation of new courses that maintain sustainable access to the PPE. After all, as noted in the RIAI’s statement, architecture’s importance in the symbiotic development of the built landscape with the abstract social values of the people it shelters exists in governmental policy [6]. High-quality design of the future built environment, and surely by consequence, the place and skills of its future architects, is in its heart.

‍

Update 04.05.24: UCD is reopening the Professional Diploma (Architecture) next January (2025) with a limit on forty places. A process of random selection is being applied for these places. Further details are available here.

The last decade had seen technology companies grow at a rate at which commercial property developers cannot keep up [1]. The majority of office space had been designed on a speculative basis. Build a ‘Grade A’ office, and they will come – but this is changing. Demand no longer exceeds supply, and the way we work has changed, while the way we occupy our offices is changing too. With lower occupancy and flexible working, the role of the ‘HQ’ has arguably become more important in its physical presence for larger companies. An office location, design, and provision of amenities are the bricks-and-mortar branding an organisation often requires. The machismo associated with office buildings of the past is no longer the best means to externalise one's values. Hugh Pearman once described Wilford & Sterling’s No. 1 Poultry as “exuding an astonishing sense of power and purpose” [2]. Kevin Roche, decades earlier, used similar power and purpose to make the workers of the Ford Foundation feel important. In an Irish context, Arthur Gibney strove to make the user feel important in Merrion Hall (1973), introducing his client to the Burolandschaft concept of office interiors, and an "exercise in the geometry of the module" [3] in both building and landscape terms, accentuating the structure of the pre-cast concrete frame. The theory goes that these important workers tended to be happier, more productive, and stay with the company longer. However, the design of these workplaces is changing again, and the changing culture of work is the first reason why.

‍

The second reason is the elephant in the room. According to the UKGBC, 80% of buildings that will be occupied in 2050 have already been built [4]. 85% of Irish office buildings are below a B rating [5] and c. 15% of commercial buildings in Ireland are vacant [6]. We have an increasing amount of low-grade office space, bound for obsolescence – the dreaded stranded asset again. A change of use to residential makes perfect sense for some buildings, but not all. Site values, and potential return on office developments still hold more value than an occupied block of apartments in central locations. The structural design of more recent office buildings also limits the potential change in to residential. The office building of twenty-first-century Dublin, with small atria, deep floor plates, and bulging plot ratios are not well suited to change of use. If we believe in a future for the office, then we need architecture to ensure existing buildings can become offices of the future.

‍

‍

What does this mean in design terms? Simply put, this is about design either side of the facade, while the facade remains. Feature facades have become ubiquitous with high-end new build offices – leading to monikers such as the ‘Cheesegrater’, ‘Gherkin’, etc., which all add to the value a potential tenant puts on their choice of building. These building exude a company’s core perception of itself, and its place in its community. Fit-out design, and place making give tenants a real ability to make staff feel important, and, of course, to be good neighbours. The opportunity for a cloud-based company to drop anchor and show their staff, and indeed their community, that they care is most often done through building. The best building to do this in, is one that already exists.

‍

We need to embrace the large-scale refurbishment of existing office buildings to provide the next wave of ‘new offices’ as and when they come. The way we have designed speculative offices in the recent past, with an unknown future user, has been wasteful. We have provided fit-outs to entice a tenant, which will subsequently be ripped out and replaced. We have designed structures, vertical circulation, and sanitary spaces to allow for maximum occupancy, when this is often not required. The constraints that come with an existing building should, and can, be embraced. Floor-to-ceiling minimums of 2.8m are an arbitrary, agent-led, recommendation without taking in to account the depth of the floor plate. The over-design for floor loadings, mechanical ventilation, WC provision, lifts, etc. all encourage us to build new. As architects, we can strive to prove the workability of retention, and more so prove that future workplaces can change, grow, and adapt as required.

‍

‍

The main reason to retain what we have, is not accreditation led – it is common sense. We have an abundance of flexible buildings in Dublin, and few have been designed to be flexible. The houses of Merrion Square were not designed to cater for tenements, nor offices, but they have operated as both throughout theire lifetime. 1970s speculatively built offices were not designed to be converted into apartments, but they are well suited to it. We don’t know what flexibility we are designing into the office buildings of the last decade, but it is our job as architects to make it work, and to lead the conversation in designing the headquarters of the future.
